    4JE-22Y-40P Semi Hermetic HVAC Reciprocating Compressor

    Ask Lasest Price
    Model Number : 4JE-22Y-40P
    Certification : CE
    Price : Discussed
    Payment Terms : T/T, Western Union
    Supply Ability : 1000000 pieces/ year
    Delivery Time : 5-7 working days
    • Product Details
    • Company Profile

    4JE-22Y-40P Semi Hermetic HVAC Reciprocating Compressor

    Semi Hermetic Reciprocating Compressor 4JE-22Y-40P for HVAC
    Highlights
    Outstanding efficiency in wide application range
    Reliable design/well-known product
    Enhanced application limits
    Optimal internal gas flow
    Very compact design
    Product versions
    Motor version 1: MT and AC applications
    Motor version 2: LT and MT applications
    Motor version 3: For R134a MT applications
    Capacity control for high full- and part-load efficiency
    VARISTEP (mechanical capacity control)
    VARIPACK (in-house frequency inverter at )
    Suitable for variable-speed drive (VSD)
    IQ MODULE
    Protection
    Monitoring
    Analysis
    Operation
    Communication
    COMPRESSOR ECOLINE 4JE-22Y (OR 4J-22.2Y)
    DISPLACEMENT (1450 RPM 50HZ): 63,5 M3/H
    DISPLACEMENT (1750 RPM 60HZ): 76,64 M3/H
    NR. OF CYLINDER: 4
    MAXIMUM PRESSURE (LP/HP): 19/32 BAR
    WEIGHT: 190 KG
    CONNECTION SUCTION LINE: 42 MM - 1 5/8"
    CONNECTION DISCHARGE: 28 MM - 1 1/8"
    MOTOR PROTECTION: SE-B2
    ENCLOSURE CLASS: IP54
    VIBRANTION DAMPERS: STANDARD
    OIL CHARGE: 4 LT
    MOTOR VERSION: 1
    MOTOR VOLTAGE: 380-420V Y-3-50HZ
    STARTING CURRENT: 97 A Y
    MAXIMUM OPERATING CURRENT: 37,2 A
    Product nameRefrigeration compressor
    ApplicationHVAC
    MOQ1 SET
    RefrigerantR134a
    Net weight187kg
